ΡΕΛΕ FINDER l 24VDC 10A/250VAC 10A/30VDC

Manufacturer FINDER
Type of relay electromagnetic
Contacts configuration SPDT
Rated coil voltage 24V DC
AC contacts rating @R
(at resistive load) 10A / 250V AC
DC contacts rating @R
(at resistive load) 10A / 30V DC
Contact current max. 15A
Switched voltage max. 220V DC, max. 250V AC
Relay variant miniature
Mounting PCB
Coil resistance 1.6kO
Coil voltage min. 18V DC
Coil voltage max. 36V DC
Body dimensions 19x15.5x15.5mm
Coil power consumption 400mW
Operating temperature -40...85°C
Relay series 36.11
Contact material AgSnO2
Terminal pitch 2mm
