562401 ΕΝΙΣΧΥΤΗΣ ''EasyF'' FM-V-U-U
Click to enlarge
Share:
- Item Code: EDSN070885
- Help Code: 12-15-0004
-
Availability:
In Stock
Important: For pick-up from our store service please contact us BEFORE you visit our store in order to avoid any inconvenience.
Item Description
Product description:TELEVES MATV amplifier MINIKOM with 4 inputs [VHF-FM-UHF1-UHF2]. Equipped with 4G-LTE filter with ON/OFF switch.
Technical Features:
- LTE ON/OFF switch
- Bandwidth:MHZ 174-400/88-108/470-862 [790 LTE ON]
- Inputs: VHF-FM-UHF1-UHF2
- Output: 1
- TEST output: -30db
- VHF 32/22, UHF 38/28
- Low/High gain switch
- 0 to -20db individual attenuators
- DC ON/OFF switch
- DC Bypass: mA 200/ max. 400
- Output lenel (DIN 45004B): dB΅V 117
- Noise figure: dB VHF 7 FM 10 UHF1-UHF2 8.5
- Power supply: 196 ··· 264 / 50-60 Hz
- Power consumpton selectable
- Ground output
- LED signal presence
- Operating temprature
- IP20
- Easy installation design
- Dimensions: 103 x 103 x 50 ???.
