Digital multimeter; LCD (4000); 3x/s; -20-1300°C;

Click to enlarge

Digital multimeter; LCD (4000); 3x/s -20-1300°C measures temperature, humidity, illumination and sound level

Manufacturer: AXIOMET
Item Code: 800049810006
Help Code: AX-190A
Availability: In Stock
Important: For pick-up from our store service please contact us BEFORE you visit our store in order to avoid any inconvenience.

106.90€ 106.9 VAT included

Item Description

Meter type	digital multimeter
Display	LCD (4000)
Sampling	3x/s
DC voltage measuring range	0,1m...400m/4/40/400/600V
DC voltage measuring accuracy	±(1,5% + 4 digits)
AC voltage measuring range	0,1m...400m/4/40/400/600V
AC voltage measuring accuracy	±(1% + 4 digits)
DC current measuring range	0,1µ...400µ/4000µ/400m/10A
DC current measuring accuracy	±(1% + 2 digits)
AC current measuring range	0,1µ...400µ/4000µ/400m/10A
AC current measuring accuracy	±(1,5% + 2 digits)
Resistance measuring range	0,1...400/4k/40k/400k/4M/40MΩ
Resistance measuring accuracy	±(1,5% + 2 digits)
Capacitance measuring range	10p...50n/500n/5µ/50µ/100µF
Capacitance measuring accuracy	±(3% + 5 digits)
Frequency measuring range	0,001...5/50/500/5k/50k/500k/10MHz
Frequency measuring accuracy	±(1,2% + 3 digits)
Temperature measuring range	-20...1300°C
Humidity measuring range	33...99% RH
Sound level measuring range	35...100dB
Sound level measuring accuracy	±5dB
Duty cycle factor	0.1...99.9%
Illumination measurement	0.001...40klux
Diode test	1,4mA, 2,8V
Continuity test	acoustic signal for R<50Ω
Overall dimensions (W x D x H)	78 x 48 x 170mm
Weight with battery	335g
Power supply	1 battery 9V 6F22
Conform to the norm	EN61010 1000V CAT III, EN61010 600V CAT IV

Measuring instrument features:

Standard equipment:
