5575 Central T.0X AMPLIFIER
- Item Code: EDSN071184
- Help Code: 12-33-0015
-
Availability:
In Stock
Important: For pick-up from our store service please contact us BEFORE you visit our store in order to avoid any inconvenience.
Item Description
Product description:Τ.0Χ 5575 is a high power amplifier for the signals processed in a T.0X headend. It features low distortion of second and third order allowing high output voltage (typical values of 120dBμV). It also has two inputs, which allows mixing of channels processed from its own headend and channels from other sources and Test output.
Technical features:
- Frequency range MHz: 46...862
- Gain dB: 44 ±2,5
- Attenuation dB: 20
- Test output attenuation dB: -30
- Output level dBμV: 105 (42 CH CENELEC)
- Output voltage dBμV: 120 typ (118 min) (DIN 45004B)
- Noise figure dB: < 11
- Return losses dB: > 10
- Impedance Ω: 75
- Power supply V: 24
- Consumption mA: 450 max
- Temp. operation C: 0 ... 45
- Protection Level: IP 20
- 2-year warranty
