2335 T.0X Optical RX 87-2150 MHz w/PSU 220Vac

 Click to enlarge



      Share:
  • Item Code: EDSN070964
  • Help Code: 12-33-0201
  • Availability: Pre-Order
    Important: For pick-up from our store service please contact us BEFORE you visit our store in order to avoid any inconvenience.
354.48€ 354.48
VAT included
Buy now WishList Compare
Product was successfully added to cart
Item Description
Product description:

TELEVES 2335 is a receiver that the original RF signal that has previously been converted by a fiber optic transmitter..Multi-window input (1200 ···1600 nm). Wide input dynamic range (-10 to 6 dBm). RF amplified output capable of delivering: 114dBμV in MATV, and 117dBμV in SAT IF. Control signals available for monitoring optical input signal. Equipped with tension-free connections (relay) for use as an alarm when the received optical power falls.


Technical features:

INPUT F.O. Forward path

- Wavelength nm: 1200...1600
- Detection bandwidth MHz: 1...3000
- Optical power received (max) dBm: 4/6
- Optical connector SC/APC

OUTPUT RF Forward path

- Frequency range MHz: 87...2150
- High RF output power (114dBμV in MATV and 117dBμV in IF).
- Max. input level for CSO & CTB >= 60dB (*)
(*) Input: 41 TV CH CENELEC and 1 complete satellite transponder. The input attenuator in 0 dB position.
- Regulation margin dB: 0 - 18
- Impedance: Ω 75

GENERAL

- Powering voltage Vdc: 12 - 24
- Consumption 24Vdc mA: 155
- Ingress protection IP 20
- Dimensions (WxHxD) mm: 50 x 216 x 175
- 2-year warranty
