5341 AMPLIFIER 5in. 123dBuV

Product description:

TELEVES MATV 5 in/1 out - BI-FM/BIII/BIV/BV/UHF amplifier


Technical features:

- Mains supply input (196-264V~ 50/60Hz)
- Ground connection
- On LED
- MATV output test
- MATV signal output
- UHF signal input. Current output for preamplifiers.
- BV signal input. Current output for preamplifiers.
- BIV signal input. Current output for preamplifiers.
- BIII signal input. Current output for preamplifiers.
- FM signal input. Current output for reamplifiers.
- UHF input attenuator
- BV input attenuator
- BIV input attenuator
- BIII input attenuator
- FM input attenuator
- Status LED. “On” position means signal presence.
- FM Amplifier Selection
- Power Voltage Selection for preamplifiers 12 Vdc. (ON/OFF)
- Selection of high gain / low gain
- Inputs: FM/BIII/BIV/BV/UHF
- Frequency range:MHZ 88-108, 174-370/470-590/614-862/470862
- Gain (high):dB 39,25/44/48/50/50
- Gain (low):db 31,21/36/39/40/40
- Output level (DIN 45004B) dB΅V 123
- Maximum output level (EN 50083) CTB,CSO,XMOD (35ch -60dB) dB΅V 120
- Noise figure: dB 8, 10/6,5/9/9/8
- Attenuator inputs UHF and VHF: 0-20
- Attenuator inputs UHF and VHF: max.W16
- Max. consumption preamplifiers: mA50@12Vdc
- Operating temperature: C -5 . . . +45
- Protection index: IP20
