534411 MICROKOM AMP.MATV 30/35dB

 Click to enlarge



      Share:
  • Item Code: EDSN071331
  • Help Code: 12-14-0013
  • Availability: In Stock
    Important: For pick-up from our store service please contact us BEFORE you visit our store in order to avoid any inconvenience.
115.90€ 115.9
VAT included
Buy now WishList Compare
Product was successfully added to cart
Item Description
Product description:

The line amplifier Televes 534411, with return path configuration by means of internal jumpers, both system and cable equalisers and Input and Output -20 dB test connectors, Plus interstage equalizer provides the solution to each application specified for.


Technical features:

Forward path
- Frequency range MHz: 85 - 1006
- Gain dB: 35
- Noise figure: 7 db
- Vout DIN 45004B dB΅V: 121
- Vout EN 50083-3 IMD3 (2 ch, -60 dB): 105
- Vout EN 50083-3 CTB, CSO, XMOD (42 ch, -60 dB): 105
- Input Attenuator (2dB steps) dB: 0...18
- Return Losses: >12
- Nominal value deviation: ±1
- Test output: -20 db

Return path
- Frequency range MHz:5 - 65
- Gain dB: 28
- Noise figure: <6
- Vout DIN 45004B: 118 dbμV
- Input Attenuator (2dB steps): 0...18
- Return Losses dB: >12
- Nominal value deviation: ±1
- Test output: -20 db

General
- Mains voltage Watt: 99-253 / 50-60 hz
- Power consumption Vac/Hz: 5
- Operating temperature C: -10... + 45
- Protection index: IP 20
- Connectors HF type F-Female
- Dimensions mm: 185x80x35
