7485 LINE AMPLIFIER TERR/SAT 20dB PASSIVE
- Item Code: EDSN070959
- Help Code: 12-14-0004
-
Availability:
In Stock
Important: For pick-up from our store service please contact us BEFORE you visit our store in order to avoid any inconvenience.
Item Description
Product description:Amplifier powered by means of coaxial cable to adapt the input level in the headend equipment.
The ref. 7485 also allows the powering bypass current for LNB conversor.
Technical features:
MATV:
- Frequency range: ?Hz 470-862
- Gain dB: -2,5
- Output level DIN 45004 B dB΅V -
- Noise figure dB -
IF:
- Frequency range MHz: 950-2150
- Gain dB: 20
- Output level DIN VDE0855/12 dB΅V: 112,5
- Noise figure dB: <5,5
- Consumption mA: 60 (12-18 VdC)
- Max. bypass current mA: 500 (S-E)
