405101 LTE Filter (ch.21-58) EasyF

 Click to enlarge



      Share:
  • Item Code: EDSN070954
  • Help Code: 12-21-0007
  • Availability: In Stock
    Important: For pick-up from our store service please contact us BEFORE you visit our store in order to avoid any inconvenience.
11.61€ 11.61
VAT included
Buy now WishList Compare
Product was successfully added to cart
Item Description
Product description:

4G-LTE filter [ch. 21-58], “Easy-F” connection. To protect the UHF band allocated to TV services from interferences caused by the data transmission on the LTE band. Two types of LC filters with different performance in terms of rejection and performance for applications where channels above Ch58 are in use.


Technical features:

- Connector type: Easy-F
- Bandwidth MHz: 470 - 774
- Through Loss dB: 1
- Through loss at the edge of the frequency range: dB 6
- Rejected band MHz 791 - 862
- Isolation in the rejected band dB >25
- Dimensions (Wid x Hei x Dep) mm 88 x 79 x 42
- Operating temperature: -5 ... +45 C
- Protection Index IP 23
