Transformer Encapsulated 2.4VA 230VAC 12V 0.2A

 Click to enlarge



      Share:

Transformer: encapsulated; 2.4VA 230VAC;12V; 0.2A

  • Manufacturer: INDEL
  • Item Code: 800080210000
  • Help Code: 12V/2.4VA
  • Availability: In Stock
    Important: For pick-up from our store service please contact us BEFORE you visit our store in order to avoid any inconvenience.
5.00€ 5
VAT included
Buy now WishList Compare
Product was successfully added to cart
Item Description



Manufacturer INDEL
Type of transformer encapsulated
Power 2.5VA
Primary voltage 230V AC
Secondary voltage 1 12V
Secondary winding current 1 0.2A
Mounting PCB
Pri./sec. insulation strength 4kV/60s
IP rating IP00
Conform to the norm PN-EN 61558
Thermal class Ta40B
Secondary winding terminals 7-9
Primary winding terminals 1-5
Insulation class II
Weight 120g
A dimension 41.4mm
A1 dimension 29.2mm
B dimension 35.2mm
B1 dimension 24.7mm
C dimension 22.2mm
C1 dimension 16.7mm
M dimension 25.1mm
P dimension 5mm
